EX REAL is a higher performance with high level of practical detail crawler. The 1.4mm thick C-Channel steel frame with entire kit M7 steel linkages enhance the automobile strength and durability. The front engine & 2 rate gearbox setup follows the real crawler design, so that the CG are at leading for better accelerating traction. Besides, it keeps the room for individual to complete the preferring inside designs. The metal bevel gear with metal solid axle, knuckes and top linkage produce significant ground approval and greater checking out ability. Your whole new 75mm aluminum oil damper enables more oil volume to give you a much better shock absorbency. EX REAL includes all refined adjustable settings: wheelbase, camber and battery tray to find the best performance in huge difference terrains. Also with the stealth human body mount and realistic front and back bumper needed seriously to state EX REAL is a top price-performance ratio realistic crawler which makes you have the best realistic crawler experience.
1.4MM THICK C-CHANNEL FRAME
1.4mm dense C-Channel metal framework with whole kit M7 metal linkages enhance the automobile strength and durability.
REALISTIC 2 SPEED GEARBOX & CENTER TRANSFER CASE
EX REAL includes 2 rate transmission gearbox and transfer instance with effortless adjustable motor gears spacer. Enable driver to shift into low range for lots more torque while climbing hills and high range for blasting down the hills(GEAR RATIO: first SHIFT 2.6:1 | 2ND SHIFT 1.69:1). Offer it the realistic and greatest low speed crawling control. Inside the gearbox are used steel gears to improve the strength and durability. Furthermore, the front motor & 2 rate gearbox setup follows the true crawler design, so the CG reaches leading for better accelerating traction. Besides, it keeps the room for individual to complete the preferring inside designs.
POWDER METALLURGY GEARS & METAL SOLID AXLES
EX REAL makes use of powder metallurgy gears to increase the strength and supplying smooth area finish greater dimensional accuracy and part-to-part consistency, increased EX REAL performance security.
KNUCKLES & DIFF PROBLEMS
The knuckles design makes top linkage closer to the chassis to improve the ground clearance which can decrease the likelihood of blocking by the hurdles, that is a huge advantage for climbing.
12° KINGPIN INCLINATION & ADJUSTABLE 0~20° CAMBER
EX REAL includes 12°Kingpin inclination makes steering becomes smoother. Incorporating adjustable 0~20° camber to level the axle to maximum the car performance in distinction terrains.
1.9 INCHES BEADLOCK RIMS WITH REALISTIC RUBBER TIRES
The beadlock rims included golden screws to enhance the look of the vehicle. High traction realistic plastic tires, features huge and deep lug provides high levels of traction in every off road conditions.
FUNDAMENTAL WATERPROOF RECEIVER CASE
For better fat circulation the receiver instance is put together at the rear part associated with the vehicle.
The receiver case includes rubber seal to deliver the basic water-resistant function; If user wishes a more protected, user may use the silicone spray/paint(NOT INCLUDED) to totally protect the truth.
STEALTH BODY MOUNTS
To match with the realistic look, EX REAL included a set of stealth body mounts
to stop the body articles exposed and affect the entire appearance. But EX REAL also included the conventional human anatomy posts for user to use it on normal Computer human anatomy shells.
ENTIRE KIT M7 METAL LINKAGES
Metal linkages increases entire vehicle strength and durability.
2.0MM FRP ADJUSTABLE BATTERY TRAY
Adjustable battery tray suited to standard or quick pack battery.
NOTE: Except motor is included, all other electronics and human body shown in pictures offered separately.
NOTE: Photos and descriptions depicts pre-production model, final manufacturing kit may at the mercy of alter without notice.
