Competition Design
The light-weight associated with the professional 120A was created to meet the users’ demands of a light
weight product for several marine competition which fat is an issue of rate and
stamina. The core system for top-level competition services and products guarantees the user
first-class control and “abundant” programmable parameter products for various
competition environments. (* The ESC is very applicable to ECO/MONO1)
Splash-proof
The whole circuit board and all the elements on it went through nano-coating
therapy; this will make the Seaking professional 120A ESC splash-proof.
High Voltage Built-in BEC
The integral switch mode BEC with a maximum output of 8A and adjustable
voltage of 6V/7.4V make the ESC appropriate for various high voltage servos.
High Durability & Reliability
Reliable hardware (i.e. MOSFETs with incredibly low internal opposition) coupled with higher level
computer software (features low-voltage cutoff protection, thermal protection, throttle signal loss security, and
etc) guarantees the durability and dependability of the ESC and relevant gadgets.
Innovative Turbo Function
The world’s very first marine ESC to have implemented the turbo timing function
which will supply the user the edge within the competition with instant turbo boost.
Programming/Upgrading Wirelessly
With Hobbywing’s WiFi module and iPhone or an Android os phone (utilizing the
HOBBYWING WiFi Link computer software set up), the user can from another location plan
parameters or update firmware without making the control stand.
Efficient Cooling System
The Hobbywing patented heat-conductive copper club address in the power board
regarding the ESC combined with water cooling module efficiently and efficiently
transfers temperature to the outside thus keeping your ESC as cool as you can.
Regular Firmware Updates without Charge
You can upgrade the ESC using the Hobbywing WiFi/USB LINK pc software, a WiFi
module/LCD program box and a smartphone /laptop. Hobbywing updates its ESC
firmware frequently providing you with upgraded features more frequently when available.
Item Specification
Type
- Brushed/Brushless : BL
- Waterproof : Waterproof (IP55)
Specifications
- Cont./Peak Current : 120A/760A
- InputVoltage : 2-6S Lipo/6-18 Cell NiMH
- BEC production : change Mode: 6V/7.4V,4A
Wires & Connectors
- Input Wires : Red-12AWG-200mm*1/Black-12AWG-200mm*1
- Output cables : Black-12AWG-150mm*3
- Input Connectors : No
- Output Connectors : 4.0mm Gold Connectors (Female)
ESC Programing via
- Transmitter : Supported
- LED Program Box : maybe not Supported
- LCD Program Box : Supported
- WiFi Module : Supported
- Program Port : Separate Program Wire
Firmware
- Firmware Upgrade : Supported
Size & Weight
- Size : 96.6x37.9x10.3mm
- I.D./O.D. of this Water Cooling Pipe : Ф2.0/5.5 mm
- Weight : 87.5g
Applications
- ECO, Mono1/Other Competition Boats (≤100cm)
