HOBBYWING XRotor PRO 25A Circular (Black Color)- 30902022  [HW-30902022]

Easy Installation

Motor could be closely mounted onto the ESC, which significantly simplifies wiring and
installing of the propulsion system.

Popular Choice

The mount is excellently suited to the most popular 16mm
(outer diameter) carbon fibre supply tube.

Excellent Protection

The incorporated framework of the ESC and engine mount has
excellent dustproof and splash proof protection.

DEO Technology

The DEO (Driving effectiveness Optimization) technology implemented
in the ESC has numerous advantages:
● Active braking. When reducing the throttle amount, the engine will
decelerate quickly. This particular feature allows pilots to easier
perform all maneuvers like razor-sharp turns, altitude changes, and
unexpected braking.
● Higher driving efficiency, longer flight time.
● Lower ESC heat and an even more reliable procedure .
* various companies call this technology by different names;
“SimonK” calls it “Comp_PWM”, “BLHeli” calls it “Dampaning-light”
and Kontronik calls it “Active Freewheeling”.

Easy to Use

Highly intelligent and adaptive standard settings like
auto-adjusting timing for simple operation.

Product Specification

Product Number

Specifications

• Cont./Peak Current : 25A/40A
• LiPo Cells : 3-6S LiPo
• BEC Output : No

Wires & Connectors

• Input Wires : Red-18AWG-300mm*1/Black-18AWG-300mm*1
• Output Wires : No
• Input Connectors : No
• Output Connectors : No

Features

• Throttle Range Calibration : Supported
• Stick Programming : Supported
• DEO : Supported
• OneShot Mode : maybe not Supported
• Timing : Supported
• Light Color : Not Supported
• Motor Rotation : Not Supported

Size & Weight

• Size : 89.3x44.5x20.9mm
• Weight : 50.5g(w/ Motor Mount)
