HOBBYWING XRotor Video Transmitter - 30505000  [HW-30505000]

Tiny Size & Exquisite Design

The STM32F405 MCU which features the effective computing capability and super-high
operating frequency enables the FC to perform the PID and gyro with higher frequency.

Voltage-regulating Filter,
Adjustable Transmitting Power &
Adjustable Voltage for Camera

The integrated voltage-regulating filter isolates the disturbance
of the energy system through the VTX to guarantee the image stays
clear and stable as soon as the aircraft flies at high rate. The
adjustable transmitting energy (0/25mW/200mW) and
stable production energy guarantee long transmission distance.
For different applications, the supply voltage the camera
is adjustable between 5V and 12V.

48 Adjustable Frequencies & Race Bands Supported

The 6 frequency teams with 8 channels in each group form 48 frequencies; the frequency circulation is
applicable to many receiving equipment. On the list of regularity groups, team D and group F are
regularity groups for competition; users may use the 8 frequencies in the same group simultaneously
without fretting about interference.

Stack-up Installation Supported

When combining the VTX with the Hobbywing F4 flight controller
and XRotor Micro 40A 4-in-1 ESC, the installation is extremely
incorporated, simple and easy convenient, and makes the aircraft
more applicable to your FPV Racing.

Item Specification

Part No.

• 30505000

Basic Features

• Input Voltage : 7-25V
• Current : 70mA / 100mA / 250mW @ 12V
• Output Voltage : 5V/12V Adjustable (limited to powering the webcam)
• Transmitting energy : 0/25mW/200mW Adjustable
• Transmitting Frequency Range : 5.3GHz-5.9GHz
• Transmitting Frequencies : 48 Frequencies Adjustable
• Antenna Connector Type : MMCX-to-SMA (a MMCX-to-SMA cable is roofed in box)

Size & Weight

• Size : 36x36mm
• Mounting Holes : 30.5x30.5mm
• Weight : 5g
