Serpent SER904006 Viper 990E 4wd 1/8 EP  [SER904006]

Serpent SER904006 Viper 990E 4wd 1/8 EP
Price:
USD$568.89
Brand:
Serpent
Model:
SER904006
Condition:
Brand New
Write a review
Brand new key features

  • The ultra-narrow chassis is milled down seriously to permit the cheapest possible mounting for the batteries dish including enhancing the general flex characteristics.
  • The main area of the chassis features 3 NACA ducts the cooling for the speedo plus the motor
  • The engine is placed as low as possible by machining the chassis beneath it. This improves the centre of gravity as well as the cooling from bottom.
  • The back of chassis has a slot. This has become a critical feature associated with Nitro 990. It has to do with adjustable flex.
    It also holds 2 metal countersunk screws that become a counterpart associated with down-stop screws. This helps to help keep the down-stop more accurate and consistent

  • The overall flex is managed by the “backbone”, a tremendously popular feature for the 988E.
  • The front side of automobile could be adjusted to more flex by detatching the two front side screws if not usually the one on top of the servosaver.
  • The backside of car can be adjustable about the flex. The standard tail features the proven, one-piece rear plate
  • As a choice it's also feasible to make use of a softer tail making use of a optional 2-piece backside plate
  • The receiver as well as the steering servo are mounted on a tiny “radio plate” which may be effortlessly eliminated for easy access.
    The aluminium servo mounts are eccentric and certainly will be mounted in 2 ways to adjust them toward model of servos.

  • A corner end is completely brand new. It features a new design allowing an re-active toe-change and avoid any binding anyway!
  • By changing the positioning of website link the total amount of toe-gain under compression can be adjusted. The career shown may be the “neutral” position.
  • Since the top of link is replaced by a suspension arm, we additionally changed top of the pivot on upright. It's now quite simple to modify the right camber.
  • The height regarding the pivot ball is adjustable by changing the aluminium insert. You can find 3 positions
  • The upright holds an aluminium insert where in fact the ball bearings of this wheel axle sit. By doing so we can achieve an ideal roundness also under load to attain the minimum friction of the transmission feasible.
  • In in this manner it's also not that hard to remove the wheel axle/driveshaft for maintenance
  • The front side steering-block features the same construction.
  • The aluminium insert gives the same advantages as in the trunk with improved drivetrain effectivity and improved simple maintenance
  • But because this insert is eccentric, it is also possible to change the roll-centre and las making use of a trailing or leading set-up.
    Definitely the steering-blocks are still left/right symmetrical and may be properly used with option1 in addition to option2 levers.
  • The front side top suspension system bracket now has a greater design takes provides a better placement to avoid camber or caster problems simply by using bushings.
  • The new transmission is super strong, yet extremely light and a breeze to maintain.
    The pulley associated with the mid-belt is sitting on a steel adapter that is secured by a steel pin.

  • The spurgear adapter is fixed with 2 of the pins. Changing the spurgear is a breeze, simply eliminate 3 screws
  • General features

    7075 T6 Aluminium 5mm framework dish
    The 5mm aluminium chassis has perfect symmetrical form even for flex and weight circulation. The ultra-narrow framework is quite light, whilst it nevertheless continues to be strong in critical places.

  • The cable type front anti-roll club is ball raced. It is possible to change and adjust due to the available front end design. The typical cable is 2.5mm and 2 optional thicknesses can be obtained. The pivot ball website link system directs the suspension movement toward club and enables simple tweak adjustment.
  • The long durable front side lower wishbones will be the open-style hands just like the 977. An aluminium shock mount dish is screwed on the reduced wishbone. This allows the surprise attachment indicate be put further outwards improving shock motion. The front reduced arms are mounted on front brackets with nylon holders. The kit includes 2 variations: in and out. This system also allows fast and simple front drive shaft maintenance.
    Of course the 988 closed arms are usable as well

  • The left and right interchangeable top hands are mounted with 3 position nylon suspension system pin inserts. The 3 position inserts enable camber-change modifications and therefore are held in place by the anodized aluminium top brackets. Underneath the top brackets, spacers could be used to alter their angle or height. Caster is adjusted with clips on the top pivot pins. Similar clips will also be used on the low pivot pins to alter wheelbase.
  • The black colored anodized aluminium front axle has Japan made one-way bearings. Spring metal drive cups connect with the long and thin spring-steel drive shafts with CVD system. The ball raced spring steel wheel axles have actually aluminium quick-change levers. The available front end design enables quickly and simple elimination of leading axle and driveline components.
  • The central mounted seervosaver enables effortless and fast Ackermann modification. The servosaver features a high mounted insert which may be found in 3 jobs. Another 2 Ackermann jobs can be obtained in the steering blocks.
  • The rear end construction with aluminium brackets is a really open design, makes it possible for for easy of upkeep and cleaning. Dis-assembly calls for removing only some screws. Changing a belt if needed, is a simple task. The eccentric bearing holders in the backside shaft allow modification of belt stress. The entire tail could be removed as one device through the framework by removal of only a few screws.
  • The cable type rear anti-roll club is ball raced. It is installed inside rear bearing blocks and it is very easy to change and adjust. The standard wire is 2.5mm and 2 optional thicknesses can be obtained. The pivot ball website link system directs the suspension system movement towards bar and permits easy tweak adjustment.
  • The slim solid back axle in Serpent spring metal has a lightweight 9mm wide 48T pulley. Spring steel, CVD type, drive shafts connect the trunk shaft to spring steel wheel-axles with aluminium quick-change levers. An extremely durable and resilient drivetrain.
  • The rear drifting human anatomy mount which will be mounted on the up-rights with 2 arms is centred by a carbon-fibre and steel guider. The mount has 4 roles on each part available, dependent on human body shell used and traction available. The threaded holes on end of this human body mount supply the option to add further body-supports.
  • Optionals
