Lord associated with the Dance
This R/C model set up kit creates the Dancing Rider, a supremely fun 3-wheeled model that provides a fantastic lean whenever cornering. A genuine human body is included utilizing the kit, and ended up being designed beneath the supervision of famed Japanese artist Atsushi Arino. It's molded in lightweight polycarbonate, and is sold with a molded driver figure for a supplementary touch of enjoyable.
T3-01 Chassis: created for Fun
The T3-01 is a three-wheeled chassis composed of two main parts (front and rear) connected by a center link; the leading part homes R/C equipment and also the energy source, even though the rear holds the integrated gearbox and engine. Positioned in the rear of leading part, the servo applies motion toward rear area, which makes the leading slim. Support arms are relocated by the servo, and help the model to self-right in the event that it turns onto its side. At the front end, a telescopic fork has a built-in coil spring, whilst the backside features a cam-slide setup with cams on rotating pitch axis: sliding left and right, they actuate the built-in coil spring to cushion a corner. A planetary differential gear is incorporated into the trunk axle.
Specifications
Length: 260mm Width: 135mm Height: 175mm Wheelbase: 196mm Tread (backside): 91mm Tire Width/Diameter 21/61mm (Front), 25/59mm (backside) Monocoque Chassis Rear-Wheel Drive Planetary Differential Gear Front Suspension: Telescopic Fork back Suspension: Cam-Slide Gear Ratio = 10.7:1 Requires an Electronic Speed Controller (sold separately) Type 370 engine included
individually needed Things
2-Channel R/C System w/ESC R6/AA/UM3 batteries for transmitter Power supply
