Specifications:
- Direct drive gear system with better effectiveness
- Operating Voltage Range: 4.8V~8.4V
- Gear Material: Titanium steel gear
- Weight: ~42g
- Dimension: 41mm (L) x 26.5mm(W) x 20mm(H)
- Stall Torque: 10kg-cm @6V, [email protected], [email protected]
- Operating Speed(with no load): 0.065 sec/60°@6V, 0.055 sec/60°@7.4V, 0.05 sec/60°@8.4V
Enhanced features based on DCS V3 servo:
- Allow to program the below items through the optional servo program card to maximize the general servo performance.
(products: Max energy band, Turn Boost, Dead Band, Response degree, Max Torque, Turn Brake and Center Adjustment). But the servo program card is optional and it is perhaps not added to the packing
- Support SHR/SRS/SUR mode
- Hybrid titanium/steel gear for durability to enhance the most durability
- brand new upper plastic casing design for better durability
