Specs:
- Controls: Forward/Brake/Reverse
- Input Voltage: 2S-3S lipo
- BEC: 6V/7.4V selection/max ~5A
- engine Limit: 4.0T or over
- Max current: ~200A per stage
- Size: ~30.5x38x16mm
- fat: ~38g (not include wiring and fan)
Hardware:
* Change to 32-bit MCU with ultra-smooth, faster response with precise throttle and braking control. More upper end power with the exact same item function setup in comparison to Radon Pro V4.1.
* brand new PCB layout and brand new internal hardware design increase the heat dissipation and may be around 10'C below radon professional v4.1 focusing on exactly the same condition. The rate control cooling fan are removed when running small to medium track for modify/stock racing.
* Connect with outside Bluetooth unit for advanced level development and firmware change through mobile phone APPS. APPS will undoubtedly be on both IOS and Android os.
* real-time Data research through mobile phone APPS(active Input & Output Throttle, Temperature, RPM, Adv. Timing, Voltage and min. voltage, Max Temperature, RPM & Adv. Timing)
* integrated one touch On/Off switch and help outside On/Off switch.Limit edition casing with Metallic golden color in available line
Features:
- 32bit-MCU with ultra-smooth, exact throttle and stopping control
- suitable for sensored/sensorless brushless engines
- Connect with Bluetooth device for advanced development and firmware upgrade through Cellphone APPS (help Android or Apple)
- genuine information Analysis through Mobile APPS(Max, RPM, RPM, Advance Timing, Max Timing, Temperature, Max Temperature, minimal Voltage minimal voltage and ESC heat)
- Built-in one touch On/Off switch and help external On/Off switch
- Bulit-in Low voltage cut-off, Overheat security and sign loss protection
-Ext. Bluetooth is optional and is maybe not contained in the package.
