XRAY 300025 T4 2019 Specs  [XR-300025]

XRAY T4

2018 All-new Specs

• All-new ULP (Ultra Low Profile) shocks with 4mm reduced design for improved stability
• All-new ultra-low profile ULP surprise towers to support new ULP (Ultra Minimal Profile) shocks
• All-new chassis design with brand new motor mount dish place for further flex adjustment and motor moved more to center
• All-new top redesigned top deck works together the brand new layshaft bulkheads and motor mount which moves engine more to center
• All-new engine mount dish features brand new additional rearmost holes for improved traction and additional flex adjustment
• All-new engine mount decreases the framework roll with motor place more to center
• All-new in-line framework flex set-up options
• All-new ECS drive shafts are 51mm miss optimized steering and stability

General

• Designed for highest performance at all degrees of racing
• Chassis built to provide maximum traction and steering
• Reduced sensitiveness to changing track conditions, offering super-consistent performance during runs
• EFRA, ROAR, FEMCA spec compliant for stock and modified racing
• Super an easy task to build, arranged, maintain, and drive
• Developed, created and styled by Martin Hudy, produced solely by XRAY in Europe on earth's most sophisticated RC manufacturing facility
• Revolutionary on-road platform with the standard for premium quality, reliability and performance
• Premium, expert, high-competition model rushing automobile the many demanding racers
• Manufactured from premium European materials, machined making use of up to date Swiss and German machines
• Premium XRAY service & help


Chassis

• Graphite framework CNC-machined from 2.2mm premium-grade graphite material
• Chassis specifically designed for different track conditions, offering enhanced traction, steering, stability, and increased cornering speed
• Chassis has pre-drilled holes for ARS system
• Chassis features pre-drilled holes for optional components such as for instance framework weights, graphite engine guard, graphite adjustable battery owner, and battery pack strap
• Chassis designed designed for brushless engines and LiPo batteries; composite battery pack holders prevent batteries from moving in crashes
• Top deck permits installing of optional aluminum stand to change flex traits, and optional graphite steering system plate
• Bulkheads are strategically placed near to the center of the chassis to enhance steering, traction, and stability
• Layshaft bulkhead allows removal of top deck accessory screws (bearing is held by layshaft bulkhead)
• Upper bulkhead clamps function  4 optimized roll center positions
• Front & backside bulkheads enable separate front & backside diff height adjustment and belt tension adjustment
• 3mm super-low profile surprise towers lower the CG and enhance stability
• Motor mount bulkhead works with along with industry-standard brushless motors
• Centered layshaft and split bulkheads offer enhanced balance due to maximum fat distribution of the engine towards centerline, giving quicker left-right transitions
• Motor mount bulkhead is combined with layshaft bulkhead in 1 solid piece to eradicate tweak caused by connected screws
• Motor mount bulkhead is linked to aluminum engine mount dish to get rid of tweak, also provides numerous flex adjustment opportunities by adding/removing screw ahead or behind the nut, or using optional post instead of the nut
• The engine mount dish is attached to the framework via an M3 nut and an additional countersunk screw is placed ahead or behind the nut if more reinforcement will become necessary, and/or nut is removed and 1 or higher of 6 holes can be used as extra flex modification options
• Front & backside lower bulkheads take care of the anti-roll bar bearing mounting system

Suspension

• Kit includes both standard & ARS (Active Rear Suspension) backside suspensions
• ARS suspension system offers great adjustment opportunities and driving characteristics
• ARS suspension system includes ARS arms, graphite 0° C-hubs for optimal flex faculties, hard suspension block, ARS suspension block, and ARS linkage linking the holder to the suspension block
• ARS linkage angle – adjusted by adding/removing shims regarding the steering block and ARS-holder changes the toe-in characteristics associated with the back tires during chassis roll
• Aluminum suspension system holders featuring built-in Suspension Settings (ISS) for fast & simple suspension system geometry adjustment
• Suspension holders allow stronger mounting of suspension system hands, therefore the suspension geometry of the car does not change even with difficult crashes
• Suspension mounting system permits extremely free supply movement, which provides higher traction, smoother driving, and enhanced steering
• Suspension owner system allows suspension system arms become mounted separately from bulkheads making it possible for elongated chassis flex to come up with more traction
• Independent suspension system holders enable more precise and fine set-up alterations via various bushings
• Rear suspension aluminum holders feature integrated toe-in
• C-hubs available optionally in standard caster perspectives (0°, 2°, 4°, 6°); obtainable in four hardnesses (M - medium, H - difficult, G - graphite and aluminum)
• Hard front steering blocks increase steering response, decrease front tire overheating in high-traction conditions
• Small, robust steering blocks made from unique proprietary composite product, available optionally in 3 hardnesses (M - medium, H - difficult, G - graphite and aluminum), and have 2 Ackermann positions
• Rear uprights give increased stability; available optionally in 3 hardnesses (M - medium, H - difficult, G - graphite)
• back uprights function integrated 0° toe-in to prevent suspension geometry alterations in severe crashes
• Arms function revolutionary SFATM (Suspension system Flex modification), revolutionary and unique graphite stiffeners allow for super-quick suspension system flex adjustment to easily adjust the traction associated with car under different track conditions
• Suspension hands function incorporated anti-roll club mounts; rear arms function 3 different anti-roll club mounts for super-fine adjustment of this back anti-roll bar
• Suspension hands made from graphite material for improved traction and stability of car
• Anti-roll club system is mounted to the bulkheads via bearings for extra-smooth motion and maximum precision, and part play is eliminated by aluminum bushings
• Anti-roll bar height is adjustable via simple screw adjustment… fast & easy
• Front 1.4 mm & rear 1.3mm anti-roll bar cables included
• Easily-adjustable wheel offset making use of optional wheel hubs  (-0.75mm, +0.75mm, +1.5mm)

Drivetrain

• Lightweight center layshaft CNC-machined from aircraft aluminum
• 84T 48P spur gear  - extra-hard product, wobble-free design
• 38/20T (1.9) internal gearing for efficient, superior drivetrain
• Premium-quality drive belts
• C-hubs with big spaces for quick & simple assembly/disassembly of the CVDs and ECS drive shafts; stops collision of CVD or ECS drive shafts with C-hub in serious crashes
• Super-light drive axles
• Front Extra-Strong ECS drive shafts equalize the speed involving the drive shaft and wheel. With a unique 2-piece joint involving the axle together with wheel, any extreme wheel turning angle is divided in to two shallower angles without joint binding. Which means whatever the cornering rate and wheel angle, the inner wheel will not bind or vibrate. Drive through corners is more stable, more accurate, and easier to drive
• ECS drive shafts produced from world-renowned, self-developed HUDY Spring Steel; hand ground for optimum precision
• Super-lightweight Swiss 7075 T6 aluminum back drive shafts (50mm), hard-anodized, color-coated and laser-engraved, 38per cent lighter than standard drive shafts
• Super-lightweight wheel axles constructed from premium HUDY Spring Steel
• 7075 T6 aluminum wheel hubs
• Complete set of high-speed, blue-sealed ball-bearings are degreased and lightly oiled for optimum efficiency, independently controlled, selected, and inspected
• Aluminum self-locking wheel nuts

Differentials

• Super-smooth, super-light maintenance-free composite gear differential
• Adjustable gear differential stiffness via oil viscosity
• Super-light composite Front Solid Axle with XRAY’s very own smart quick-change outdrive system for simple outdrive change; no servicing or replacement of drive shaft blades needed, means reduced servicing costs

Steering

• Servo mounting system for improved stability and elimination of unwanted tweak
• Servo mount allows the servo to be suspended into the chassis centerline, providing better balance while eliminating tweak and enabling additional traction
•
• Steering is separated from framework flex, ensuring tweak-independent steering for super-precise and consistent steering characteristics
• Servo mount and graphite servo holder are mounted on framework with 3 screws and 2 centering articles to eliminate the likelihood of servo movement under hard crashes
• Servo mount includes extra gap where the battery backstop screw is mounted
• Servo mount includes extra opening for in-line flex adjustment system

Shocks

• Ultra- Low Profile (ULP) aluminum shocks even for lower CG and improved stability
• ULP aluminum shocks happen shortened by  4mm comparing to SLP shocks to offer maximum security under all track conditions, while reducing traction roll under high-traction conditions also to make the car more straightforward to drive
• Shock shafts are especially hardened for maximum strength
• Foam inserts for perfect shock rebound
• Super brief Shock Springs (4S) developed & designed for the SLP shocks

• C2.5 springs contained in the kit to fit ULP shocks together with springtime prices have been optimized to deliver maximum steering and traction
• XRAY self-developed and manufactured 4S springs are manually selected for maximum precision, equal size, and equal damping traits
• Race-tested and tuned shock positions

Bumper & Body Mounts

• Front upper and lower composite bumper made from specially-formulated material to withstand hard impacts
• Super low-profile foam bumper created from lightweight, high-resilience foam
• Foam bumper is larger for perfect human anatomy fit
• Foam bumper is made from strong but lightweight material for improved durability but maintaining the extra weight as little as possible
• Composite bumper upper owner brace helps reduce chassis breakage in difficult crashes

Assembly, Set-up, Support

• Premium 3D full-color instructions & supplementary sheets
• To fully understand the set-up opportunities we suggest the renowned HUDY Set-up Book (available for down load exclusively at www.hudy.net) that is laden up with over 50 pages of top-notch pictures and easy-to-understand RC vehicle set-up explanations
• Exclusive Virtual Online Setup Sheet database with tens of thousands of set-up sheets for competition songs round the world
• Premium, unmatched XRAY online support

Adjustment Possibilities

• Fully-adjustable front and rear suspension system geometry: caster, camber, toe, anti-dive, anti-squat, ride height, droop, track-width, roll center, wheelbase
• Adjustable gear differential tightness via oil viscosity
• Four various upper linkage positions on top bulkhead clamps
• Roll center height adjustment via shims on top bulkhead clamps
• Adjustable front side and back belt-tension control using quick-adjust system integrated into bulkheads
• Front and rear diff height adjustment making use of quick-adjust system incorporated into bulkheads
• Adjustable HUDY aluminum turnbuckles (steering, front & rear upper links, ARS)
• Multiple upper and reduced surprise mounting locations at front side and rear
• Adjustable Ackermann and bump steer
• Pre-drilled framework areas for optional framework weights in center of chassis
• Adjustable front and back anti-roll bars
• Chassis pre-drilled holes for fat balance adjustment
• Adjustable in-line flex system
