All specs are susceptible to alter without prior notice. Pre-production model is shown, last specifications may somewhat vary. In certain images optional components may be shown. All choice components aren't included and must certanly be purchased individually. Along with of some aluminum parts can vary greatly from kit to kit and some of this kits might not add all of the orange or black parts as shown. Some of the spare parts or choice components may possibly not be available at the moment into the orange or black colored color as shown. Some of the images reveal colored stickers on wing and radio tray, they are maybe not included in the kit and are found in photos only for promotional purposes. The racing human body alongside gear shown in pictures aren't contained in the kit.
Dimensions
Length:
580mm
Chassis size:
459mm
Wheelbase:
380~388mm
Width:
399mm
Weight:
1902g
Approximate operating weight:
3810g
Chassis
Chassis:
3 mm CNC-machined Swiss 7075 T6 hardcoated aluminum
Radio tray:
Composite 1-piece
Central diff top deck:
Machined laminated carbon graphite
Braces:
Composite braces (front / rear)
Suspension
Suspension System:
Adjustable suspension system with preset geometry
Back suspension:
Lower H-arm with adjustable upper camber website link
Front suspension system:
Zero Kingpin suspension with integrated adjustable caster
Rear upright:
Composite with double arm mounting and 3 roll center roles
Shocks:
Big-bore shocks with various shock pistons featuring Delrin pistons
Shock towers:
Front & rear 4.0mm alu
Drivetrain
Kind:
Full-time shaft-drive 4WD with center differential
Main:
Steel spur gear / clutchbell
Drive shafts:
HUDY Spring Steel⢠universal drive shafts
Central shafts:
HUDY Spring Steel⢠CVD drive shafts
Differentials:
Sealed, 6 gear, silicone-filled
Clutch:
Aluminum 3-shoe
Bearings:
Rubber-sealed
Gearing
Pinion:
10T front side / backside
Crown gear:
43T front side / backside
Clutchbell:
13T
Spur gear:
50T
Body, Tires, Wheels & Misc
Body:
Maybe not included
Tires:
Not included
Perhaps not included, standard 17mm hub
Fuel tank:
150cc ability with capacity-adjustment segments, with hypertonic tank lid and internal stone-type drifting filter
Modification Opportunities
Standard Adjustment:
Camber, caster, toe-in, wheelbase, kick-up, anti-squat, lower & upper roll facilities, kingpin, Ackermann, bump steer, Multi-Flex, weight balance
Engine, Exhaust system, Electronics (Radio, Receiver, Servos, Batteries), Wheels, Tires, Body, Tools, Wheel device, Receiver battery pack, gas, change, Start package, Glow heater, Paint, Charger, Universal device for several nuts and turnbuckles, Set-up book.
