XRAY 370009 X12 2019 EU Specs  [XR-370009]

XRAY 370009 X12 2019 EU Specs
Price:
USD$355.80
Brand:
XRAY
Model:
XR-370009
Please kindly input your name and email address, we will inform you once we have the restocking.
Or you may find similar product under the
R/C Models - On-Road - Pan Cars category
Write a review
alt="XRAY 370009 X12 2019 EU Specs" title="XRAY 370009 X12 2019 EU Specs"
alt="XRAY 370009 X12 2019 EU Specs" title="XRAY 370009 X12 2019 EU Specs"
alt="XRAY 370009 X12 2019 EU Specs" title="XRAY 370009 X12 2019 EU Specs"
alt="XRAY 370009 X12 2019 EU Specs" title="XRAY 370009 X12 2019 EU Specs"
alt="XRAY 370009 X12 2019 EU Specs" title="XRAY 370009 X12 2019 EU Specs"
alt="XRAY 370009 X12 2019 EU Specs" title="XRAY 370009 X12 2019 EU Specs"
alt="XRAY 370009 X12 2019 EU Specs" title="XRAY 370009 X12 2019 EU Specs"
alt="XRAY 370009 X12 2019 EU Specs" title="XRAY 370009 X12 2019 EU Specs"
alt="XRAY 370009 X12 2019 EU Specs" title="XRAY 370009 X12 2019 EU Specs"
alt="XRAY 370009 X12 2019 EU Specs" title="XRAY 370009 X12 2019 EU Specs"
alt="XRAY 370009 X12 2019 EU Specs" title="XRAY 370009 X12 2019 EU Specs"
alt="XRAY 370009 X12 2019 EU Specs" title="XRAY 370009 X12 2019 EU Specs"
alt="XRAY 370009 X12 2019 EU Specs" title="XRAY 370009 X12 2019 EU Specs"
alt="XRAY 370009 X12 2019 EU Specs" title="XRAY 370009 X12 2019 EU Specs"
alt="XRAY 370009 X12 2019 EU Specs" title="XRAY 370009 X12 2019 EU Specs"
alt="XRAY 370009 X12 2019 EU Specs" title="XRAY 370009 X12 2019 EU Specs"
alt="XRAY 370009 X12 2019 EU Specs" title="XRAY 370009 X12 2019 EU Specs"

Dimensions

  • Class: 1/12 electric pan car
  • Width: Adjustable 167mm +/- 3mm front
  • Length: 264mm (varies depending on rear tires utilized)
  • Wheelbase: 201 +/-0.5mm
  • Weight: 205g
  • Ready-to-run fat: 840 g - incl. BL system (varies based on equipment used)


Chassis

  • Chassis: EU version - 2.5mm carbon dietary fiber, CNC machined; US version - 2.0mm Swiss 7075 T6 aluminum, CNC machined
  • Body: perhaps not included, makes use of 1/12 pan automobile type


Drivetrain

  • Type: 2WD direct drive to rear axle
  • Rear Axle: Graphite shaft with ball differential
  • Primary: Spur/pinion
  • Bearings: High-speed ball-bearings (10)


Suspension

  • Front: Spring-supported, kingpin-style front suspension system with composite upper & lower suspension system arms and steering obstructs
  • back: Articulating rear motor POD adjustable via pivot-ball links, managed by rear shock absorber
  • Rear Shock: Central adjustable oil-filled surprise absorber


Geometry

  • Ride Height: Adjustable front + back
  • Wheelbase: Adjustable front
  • Camber: Adjustable front
  • Front Caster (Static): 1–14.5° fixed adjustable fixed caster
  • Front Caster (Reactive): 2.5–7.5° adjustable reactive caster
  • Track-width: Adjustable front side and rear
  • Toe: Adjustable front
  • Downstop: Adjustable rear
  • Ackermann: Adjustable with shims
  • Bumpsteer: Adjustable with shims
  • Steering: Direct linkage between steering servo saver and steering obstructs
  • Balance: Front/rear fat balance adjustable via battery pack place


Other

  • Wheels: Not included
  • Tires: perhaps not included
  • Instructions: Full-color Instruction Manual with 3D visuals
  • Set-up guide: Printed variation maybe not included. Latest full-color Set-up guide (16 pages) is installed from XRAY website. Set-up Book shows previous XRAY models in photographs included within it, though the methodology and set-up theory are the same for several 1/12 pan cars.
  • Packaging: Carton box with plastic bags with parts
  • Additionally included: HUDY Diff Grease, Authentication Certificate, parts list & exploded view, decals, oils
  • Not included: Motor, batteries, speed controller, tires, human body, steering servo, radio gear, tools
Remark :
Due to limited stock availability, please notice that some XRAY items may have to order from the factory and the ready time is around 4-6 weeks. Customer purchases the item is assumed to accept the waiting time which allows us to order directly from the manufacturer if the item is out of our warehouse.
