XRAY X12



2019 All-new Specs

  • All-new EU and United States Edition both created & optimized for particular traction conditions
  • All-new EU Edition is optimized for low-, medium-, and high-traction conditions
  • All-new United States Edition is optimized for high- and very-high traction conditions
  • All-new 2.5mm graphite framework for EU Edition with battery pack backstop grooves
  • All-new 2.0mm Swiss 7075 T6 aluminum framework with battery backstop grooves
  • All-new backside wheelbase adjustment
  • All-new top clamps with composite bushing for better durability
  • All-new bulkheads utilize new top clamps
  • All-new graphite backside brace with built-in backstop and O-ring battery mount system
  • All-new O-ring for securing the battery
  • All-new adjustable graphite battery backstop with 4 positions
  • All-new longer front side graphite bumper holder



General

  • XRAY 1/12 pan-car with authentic 100per cent self-developed XRAY parts, created and manufactured by XRAY in Europe
  • Legendary XRAY premium design, workmanship & product quality and unmatched awareness of the best details
  • Simple yet effective and proven design, well thought-out details, unmatched precision of little details
  • High-competition design with concentrate on ultra-low fat, causing super-lightweight construction
  • Optimized for interior carpet racing also outside asphalt racing



Chassis

  • EU Edition featuring CNC-machined framework from stiff custom-manufactured 2.5mm high-grade graphite product with specially-designed substance for carpeting and asphalt racing
  • US Edition featuring CNC-machined framework from premium 2.0mm Swiss 7075 T6 aluminum material
  • Chassis & back pod feature pre-drilled centerline holes for maximum fat stability adjustment utilizing HUDY Balancing Tool #107880
  • Chassis includes holes and grooves for composite battery pack backstops
  • Body posts with fully-adjustable human anatomy holders; optional super-fine +1 or +2mm human anatomy backstops designed for better still human body height adjustment
  • Chassis design allows either horizontal or vertical battery placement
  • Chassis design allows to regulate vertical battery placement
  • Chassis design enables to adjust the leading wheelbase



Front suspension:

  • High-competition, fully-adjustable front suspension system with super-clean design of most composite suspension parts
  • EU Edition featuring front reduced & top hands and steering obstructs produced from difficult material to really make the vehicle better to drive and present smoother steering
  • US Edition features unique graphite suspension system hands that reduces torsional flex regarding the hands within the corners of very-high traction tracks, making the car more reactive and more straightforward to drive
  • Shims included for adjusting upper arm position
  • Precision steering block and front upper ball bones for more exact steering
  • Bumpsteer shims for improved steering
  • Lower suspension system hands feature smart eccentric aluminum inserts for quick & simple track-width adjustment
  • Optional aluminum 0.5mm and 1.0mm eccentrics for establishing track width
  • Ride height adjustment shims for quick, exact, and hassle-free ride height adjustment for different track conditions. Group of 0.2, 0.4, and 0.6mm ride height adjustment shims are included.
  • Quick & easy front caster modification via included clips
  • All composite components manufactured by XRAY utilizing premium self-developed composite mixtures which guarantee perfect flex of this suspension components yet difficult enough to withstand hefty crashes
  • Reactive caster modification (preset 2.5°, 5.0° or 7.5°) via easy-to-change eccentric bushings
  • Ultra-precise wheel axles CNC-machined from premium HUDY Spring Steel™ also hardened and hand ground for accuracy fitment
  • High-precision, HUDY Spring Steel™ top pivot balls ensure super-fine motion of front side suspension
  • Composite lower pivot balls for smooth front suspension system movement
  • Lightweight front top 3mm adjustable HUDY Spring Steel™ camber turnbuckles can withstand hefty crashes
  • Quick & easy wheelbase adjustment by going the entire front side suspension system on the chassis 2mm front side or straight back



Steering:

  • Unique adjustable servo mount can accommodate various types of 1/12 servos, and permits modification of servo to chassis centerline
  • Floating servo will not touch framework, eliminating undesired tweak
  • Super-tiny yet robust steering obstructs with specially-designed axles prevent axle rotating while tightening the wheel locknuts
  • Pivoting front suspension system has super-smooth hardened metal kingpins supported by soft springs. Optional medium, hard, and extra-hard suspension springs available.
  • Tiny yet robust servo saver with effortless Ackermann modification via included shims
  • 4-spring servo saver for exact, smooth steering
  • Specially-designed narrow composite ball joints
  • Adjustable, super-lightweight Swiss 7075 T6 aluminum turnbuckles



Rear pod:

  • Compact, ultra-lightweight narrow rear pod composed of high-strength aluminum bulkheads, graphite brace, and strong high-grade 2.5mm graphite plates
  • Unique aluminum bulkheads and upper bulkhead clamp are CNC-machined from premium extra-hard Swiss 7075 T6 aluminum, additionally black colored coated for long life & fashionable look
  • Optional eccentric top clamps enables to regulate back wheelbase
  • Light, small pod pivot ball decreases the extra weight of moving parts and advances the movement array of a corner pod plate
  • Optimized rear pod link positions
  • Rear pod top dish includes mounting hole for optional side surprise (for various damping characteristics)
  • Premium-grade graphite upper deck provides solid attachment for surprise absorber to rear pod
  • Premium graphite rear website link brace holds the medial side tubes along with part springs and human body posts
  • Premium graphite rear website link brace permits to mount graphite adjustable battery backstop and features grooves for the O-ring which secures the battery
  • Super-easy motor top access
  • Rear pod accommodates all motors
  • Ride height shims for ultra-fine rear ride height adjustment
  • Rear differential features high-grade accuracy carbide balls (for spur gear), hardened and precision-ground metal D- shims, and premium carbide 3x8mm axial thrustbearing
  • Ultra-lightweight graphite back axle
  • Precision-molded spur gear created from XRAY's exclusive composite product, ensuring true running, super-quiet operation, super lightness and robustness for handling effective motors
  • Aluminum back hubs machined from lightweight aircraft aluminum, specially lightened and black-coated for trendy look
  • Lightweight back wheel mounting screws for paid off rotating weight
  • Aluminum backside left wheel hub with center-balanced clamping mounting system, ensures safe mounting while eliminating vibration and run-out
  • Easy rear track-width modification via included shims
  • Rear human anatomy posts are installed to your framework via a broad independently-mounted graphite holder, ensuring body downforce is properly used in the chassis
  • Rear pod weight stability can be simply modified via shims between engine and bulkhead
  • Straight side springs have significantly more consistent and smoother compression for better out-of part leaving and paid off traction rolling



Shock:

  • XRAY micro shock with comparable design to its “big brother” counterpart in XRAY’s effective T4 touring automobile platform
  • Centralized shock absorber position
  • 4 frontward, 4 rearward shock place options
  • Fully-adjustable surprise with hard-anodized aluminum surprise human body for superior durability, and additionally black-coated for trendy look
  • Fine-threaded shock human anatomy for fast & simple shock spring preload adjustment
  • Tiny, slim surprise membrane offers super-smooth damping characteristics
  • Super-soft silicone surprise O-ring for smooth operation, and enhanced sealing
  • Ultra-finely finished shock shaft with precise-molded composite surprise piston ensures optimal oil flow and smooth shock absorber action
  • Simple yet smart surprise construction enables fast & simple shock-length adjustment for downstop
  • Shock position adjustment via shimming of mounting ball studs
  • Rear pod side stability managed by side pipes which give equalized lateral damping in both guidelines while eliminating unwelcome rebound
  • Rigid centrally-mounted surprise mount stops tweak, and notably improves lateral stability
  • 1-hole piston for improved damping characteristics
  • Shock length adaptor is included to alter surprise length



Assembly & help:

  • Highest quality composite parts ensure super-precise fitment, effortless assembly, and smooth procedure of parts
  • Premium 3D full-color Instruction Manual
  • Exclusive Virtual Online Setup Sheet database with tens and thousands of set-up sheets for competition tracks round the world
  • Premium, unmatched XRAY on line help



Adjustment opportunities:

  • Front camber, caster, and toe
  • Front & backside wheelbase
  • Front & backside track-width
  • Front, center, and rear trip height
  • Front springs
  • Central surprise absorber size & position
  • Downstops
  • Pod damping
  • Bumpsteer
  • Weight balance
  • Ackermann
  • Front brace stiffness
  • Differential setting
  • Servo position
  • Battery position



Specs:



Dimensions

Class:

1/12 electric pan car

Width:

Adjustable 167mm +/- 3mm front

Length:

264 mm (varies according to back tires utilized)

Wheelbase:

201+/- 0.5mm

Weight:

205 g

Ready-to-run weight:

840 g - incl. BL system (varies based on equipment utilized)

Chassis

Chassis:

EU edition - 2.5mm carbon fiber, CNC machined

United States edition - 2.0mm Swiss 7075 T6 aluminum, CNC machined

Body:

Maybe not included, utilizes 1/12 pan car kind

Drivetrain

Type:

2WD direct drive to rear axle

Back Axle:

Graphite shaft with ball differential

Primary:

Spur / pinion

Bearings:

High-speed ball-bearings (10)

Suspension System

Front Side:

Spring-supported, kingpin-style front suspension system with upper & reduced suspension system hands and steering obstructs

Backside:

Articulating back motor POD adjustable via pivot-ball links, managed by back shock absorber

Back Shock:

Central adjustable oil-filled shock absorber

Geometry

Ride Height:

Adjustable front + back

Wheelbase:

Adjustable

Camber:

Adjustable front side

Front Caster (Static):

1–14.5° static adjustable fixed caster

Front Caster (Reactive):

2.5–7.5° adjustable reactive caster

Track-width:

Adjustable front and backside

Toe:

Adjustable front

Downstop:

Adjustable back

Ackermann:

Adjustable with shims

Bumpsteer:

Adjustable with shims

Steering:

Direct linkage between steering servo saver and steering blocks

Balance:

Front/rear fat stability adjustable via battery place

Other

Tires:

Not included

Tires:

Not included

Guidelines:

Full-color instruction manual

Set-up Book:

Printed variation maybe not included. Latest full-color Set-up guide (16 pages) could be downloaded from XRAY internet site. Set-up Book shows past XRAY models in photographs included within it, though the methodology and set-up theory are exactly the same for many 1/12 pan cars

Packaging:

Carton box with vinyl bags containing components

Furthermore included:

HUDY Diff Grease, Authentication Certificate, components list & exploded view, decals, oils

Maybe not included:

Motor, batteries, rate controller, tires, body, steering servo, radio equipment, tools
