XRAY X12



2019 All-new Specs

  • All-new EU and United States Edition both designed & optimized for particular traction conditions
  • All-new EU Edition is optimized for low-, medium-, and high-traction conditions
  • All-new US Edition is optimized for high- and very-high traction conditions
  • All-new 2.5mm graphite framework for EU Edition with battery pack backstop grooves
  • All-new 2.0mm Swiss 7075 T6 aluminum chassis with battery backstop grooves
  • All-new back wheelbase adjustment
  • All-new top clamps with composite bushing for better durability
  • All-new bulkheads utilize brand new top clamps
  • All-new graphite back brace with built-in backstop and O-ring battery mount system
  • All-new O-ring for securing the battery
  • All-new adjustable graphite battery pack backstop with 4 positions
  • All-new extended front side graphite bumper owner



General

  • XRAY 1/12 pan-car with authentic 100percent self-developed XRAY components, designed and manufactured by XRAY in Europe
  • Legendary XRAY premium design, workmanship & material quality and unmatched focus on the best possible details
  • Simple yet effective and proven design, well thought-out details, unmatched accuracy of little details
  • High-competition design with consider ultra-low weight, resulting in super-lightweight construction
  • Optimized for interior carpet racing also outdoor asphalt rushing



Chassis

  • EU Edition featuring CNC-machined framework from stiff custom-manufactured 2.5mm high-grade graphite material with specially-designed compound for carpet and asphalt racing
  • US Edition featuring CNC-machined chassis from premium 2.0mm Swiss 7075 T6 aluminum material
  • Chassis & back pod feature pre-drilled centerline holes for maximum fat balance adjustment utilizing HUDY Balancing Tool #107880
  • Chassis includes holes and grooves for composite battery backstops
  • Body articles with fully-adjustable human anatomy holders; optional super-fine +1 or +2mm human anatomy backstops readily available for better yet human anatomy height adjustment
  • Chassis design permits either horizontal or vertical battery pack placement
  • Chassis design permits to regulate vertical battery placement
  • Chassis design permits to adjust the leading wheelbase



Front suspension:

  • High-competition, fully-adjustable front suspension system with super-clean design of all of the composite suspension parts
  • EU Edition featuring front reduced & upper arms and steering blocks made from difficult material to make the car easier to drive and provide smoother steering
  • US Edition features unique graphite suspension arms that reduces torsional flex of the arms into the corners of very-high traction tracks, making the automobile more reactive and better to drive
  • Shims included for adjusting upper supply position
  • Precision steering block and front top ball joints to get more accurate steering
  • Bumpsteer shims for improved steering
  • Lower suspension system arms feature smart eccentric aluminum inserts for quick & easy track-width adjustment
  • Optional aluminum 0.5mm and 1.0mm eccentrics for setting track width
  • Ride height modification shims for quick, accurate, and hassle-free ride height adjustment for various track conditions. Set of 0.2, 0.4, and 0.6mm ride height adjustment shims are included.
  • Quick & simple front side caster adjustment via included clips
  • All composite components manufactured by XRAY utilizing premium self-developed composite mixtures which guarantee perfect flex regarding the suspension components yet hard sufficient to withstand hefty crashes
  • Reactive caster adjustment (preset 2.5°, 5.0° or 7.5°) via easy-to-change eccentric bushings
  • Ultra-precise wheel axles CNC-machined from premium HUDY Spring Steel™ also hardened and hand ground for precision fitment
  • High-precision, HUDY Spring Steel™ upper pivot balls ensure super-fine movement of front side suspension
  • Composite lower pivot balls for smooth front suspension movement
  • Lightweight front upper 3mm adjustable HUDY Spring Steel™ camber turnbuckles can withstand hefty crashes
  • Quick & effortless wheelbase modification by moving the complete front side suspension on framework 2mm front or straight back



Steering:

  • Unique adjustable servo mount can accommodate all types of 1/12 servos, and permits modification of servo to chassis centerline
  • Floating servo doesn't touch framework, eliminating unwelcome tweak
  • Super-tiny yet robust steering obstructs with specially-designed axles prevent axle spinning while tightening the wheel locknuts
  • Pivoting front suspension system has super-smooth hardened steel kingpins supported by soft springs. Optional medium, difficult, and extra-hard suspension springs available.
  • Tiny yet robust servo saver with effortless Ackermann adjustment via included shims
  • 4-spring servo saver for exact, smooth steering
  • Specially-designed narrow composite ball joints
  • Adjustable, super-lightweight Swiss 7075 T6 aluminum turnbuckles



Rear pod:

  • Compact, ultra-lightweight narrow rear pod composed of high-strength aluminum bulkheads, graphite brace, and strong high-grade 2.5mm graphite plates
  • Unique aluminum bulkheads and top bulkhead clamp are CNC-machined from premium extra-hard Swiss 7075 T6 aluminum, additionally black coated for very long life & fashionable look
  • Optional eccentric top clamps enables to adjust rear wheelbase
  • Light, tiny pod pivot ball decreases the extra weight of going components and advances the motion selection of the trunk pod plate
  • Optimized back pod website link positions
  • Rear pod upper plate includes mounting hole for optional side surprise (for different damping characteristics)
  • Premium-grade graphite upper deck provides solid attachment for surprise absorber to rear pod
  • Premium graphite back link brace holds along side it tubes plus part springs and body posts
  • Premium graphite back link brace permits to install graphite adjustable battery pack backstop and features grooves the O-ring which secures the battery
  • Super-easy motor top access
  • Rear pod accommodates all motors
  • Ride height shims for ultra-fine back trip height adjustment
  • Rear differential features high-grade accuracy carbide balls (for spur gear), hardened and precision-ground metal D- shims, and premium carbide 3x8mm axial thrustbearing
  • Ultra-lightweight graphite rear axle
  • Precision-molded spur gear made from XRAY's exclusive composite material, ensuring real running, super-quiet procedure, super lightness and robustness for handling powerful motors
  • Aluminum back hubs machined from lightweight aircraft aluminum, particularly lightened and black-coated for fashionable look
  • Lightweight backside wheel mounting screws for reduced rotating weight
  • Aluminum back left wheel hub with center-balanced clamping mounting system, ensures protected mounting while eliminating vibration and run-out
  • Easy rear track-width adjustment via included shims
  • Rear body posts are mounted towards the framework via an extensive independently-mounted graphite holder, ensuring body downforce is precisely used in the chassis
  • Rear pod weight stability can be simply adjusted via shims between motor and bulkhead
  • Straight part springs have more constant and smoother compression for better out-of corner exiting and paid down traction rolling



Shock:

  • XRAY micro surprise with similar design to its “big brother” counterpart in XRAY’s successful T4 touring automobile platform
  • Centralized shock absorber position
  • 4 frontward, 4 rearward shock position choices
  • Fully-adjustable shock with hard-anodized aluminum shock body for superior durability, not to mention black-coated for fashionable look
  • Fine-threaded surprise human body for fast & easy shock spring preload adjustment
  • Tiny, thin shock membrane offers super-smooth damping characteristics
  • Super-soft silicone surprise O-ring for smooth operation, and improved sealing
  • Ultra-finely finished surprise shaft with precise-molded composite surprise piston ensures optimal oil flow and smooth shock absorber action
  • Simple yet smart surprise construction allows for quick & effortless shock-length modification for downstop
  • Shock place modification via shimming of mounting ball studs
  • Rear pod side stability controlled by part tubes which give equalized lateral damping both in directions while eliminating unwanted rebound
  • Rigid centrally-mounted shock mount prevents tweak, and significantly improves lateral stability
  • 1-hole piston for enhanced damping characteristics
  • Shock size adaptor is roofed to change surprise size



Assembly & support:

  • Highest quality composite parts ensure super-precise fitment, effortless assembly, and smooth procedure of parts
  • Premium 3D full-color Instruction Manual
  • Exclusive Virtual Online Setup Sheet database with a huge number of set-up sheets for battle songs across the world
  • Premium, unmatched XRAY on line support



Adjustment opportunities:

  • Front camber, caster, and toe
  • Front & backside wheelbase
  • Front & back track-width
  • Front, center, and back trip height
  • Front springs
  • Central shock absorber size & position
  • Downstops
  • Pod damping
  • Bumpsteer
  • Weight balance
  • Ackermann
  • Front brace stiffness
  • Differential setting
  • Servo position
  • Battery position



Specs:



Proportions

Class:

1/12 electric pan automobile

Width:

Adjustable 167mm +/- 3mm front side

Length:

264 mm (varies according to back tires utilized)

Wheelbase:

201+/- 0.5mm

Weight:

205 g

Ready-to-run fat:

840 g - incl. BL system (varies dependent on equipment utilized)

Framework

Chassis:

EU edition - 2.5mm carbon fibre, CNC machined

United States edition - 2.0mm Swiss 7075 T6 aluminum, CNC machined

Body:

Not included, utilizes 1/12 pan car kind

Drivetrain

Kind:

2WD direct drive to rear axle

Rear Axle:

Graphite shaft with ball differential

Primary:

Spur / pinion

Bearings:

High-speed ball-bearings (10)

Suspension

Front:

Spring-supported, kingpin-style front suspension system with upper & lower suspension hands and steering obstructs

Backside:

Articulating back engine POD adjustable via pivot-ball links, controlled by back shock absorber

Rear Shock:

Central adjustable oil-filled surprise absorber

Geometry

Ride Height:

Adjustable front + backside

Wheelbase:

Adjustable

Camber:

Adjustable front

Front Caster (Static):

1–14.5° fixed adjustable static caster

Front Caster (Reactive):

2.5–7.5° adjustable reactive caster

Track-width:

Adjustable front side and rear

Toe:

Adjustable front

Downstop:

Adjustable rear

Ackermann:

Adjustable with shims

Bumpsteer:

Adjustable with shims

Steering:

Direct linkage between steering servo saver and steering obstructs

Balance:

Front/rear weight balance adjustable via battery place

Other

Wheels:

Perhaps not included

Tires:

Not included

Instructions:

Full-color guide

Set-up Book:

Printed variation not included. Latest full-color Set-up Book (16 pages) could be downloaded from XRAY site. Set-up Book shows past XRAY models in photographs contained within it, however the methodology and set-up theory are exactly the same for many 1/12 pan vehicles

Packaging:

Carton field with plastic bags containing components

In addition included:

HUDY Diff Grease, Authentication Certificate, parts list & exploded view, decals, oils

Not included:

Engine, batteries, speed controller, tires, human body, steering servo, radio equipment, tools



Remark :
Due to limited stock availability, please notice that some XRAY items may have to order from the factory and the ready time is around 4-6 weeks. Customer purchases the item is assumed to accept the waiting time which allows us to order directly from the manufacturer if the item is out of our warehouse.
