XRAY 370702 X1 2017 Specs  [XR-370702]

XRAY 370702 X1 2017 Specs
Price:
USD$349.00
Brand:
XRAY
Model:
XR-370702
Please kindly input your name and email address, we will inform you once we have the restocking.
Or you may find similar product under the
R/C Models - On-Road - Formula Cars category
Write a review
alt="XRAY 370702 X1 2017 Specs" title="XRAY 370702 X1 2017 Specs"
alt="XRAY 370702 X1 2017 Specs" title="XRAY 370702 X1 2017 Specs"
alt="XRAY 370702 X1 2017 Specs" title="XRAY 370702 X1 2017 Specs"
alt="XRAY 370702 X1 2017 Specs" title="XRAY 370702 X1 2017 Specs"
alt="XRAY 370702 X1 2017 Specs" title="XRAY 370702 X1 2017 Specs"
alt="XRAY 370702 X1 2017 Specs" title="XRAY 370702 X1 2017 Specs"
alt="XRAY 370702 X1 2017 Specs" title="XRAY 370702 X1 2017 Specs"
alt="XRAY 370702 X1 2017 Specs" title="XRAY 370702 X1 2017 Specs"
alt="XRAY 370702 X1 2017 Specs" title="XRAY 370702 X1 2017 Specs"
alt="XRAY 370702 X1 2017 Specs" title="XRAY 370702 X1 2017 Specs"
alt="XRAY 370702 X1 2017 Specs" title="XRAY 370702 X1 2017 Specs"
alt="XRAY 370702 X1 2017 Specs" title="XRAY 370702 X1 2017 Specs"
alt="XRAY 370702 X1 2017 Specs" title="XRAY 370702 X1 2017 Specs"
alt="XRAY 370702 X1 2017 Specs" title="XRAY 370702 X1 2017 Specs"
alt="XRAY 370702 X1 2017 Specs" title="XRAY 370702 X1 2017 Specs"
alt="XRAY 370702 X1 2017 Specs" title="XRAY 370702 X1 2017 Specs"
alt="XRAY 370702 X1 2017 Specs" title="XRAY 370702 X1 2017 Specs"
alt="XRAY 370702 X1 2017 Specs" title="XRAY 370702 X1 2017 Specs"

Dimensions

  • Class: 1/10 formula
  • Width: Adjustable 180mm front side, 185mm back (varies according to tires used)
  • Lenght: 410 mm
  • Wheelbase: 264 mm
  • Weight: 375 g
  • Ready-to-run fat: 985 g (varies based on equipment utilized)


Chassis

  • Chassis: 2.5 mm carbon fibre, CNC machined
  • Body: XRAY X1 1/10 formula type


Drivetrain

  • Type: 2WD direct drive to rear axle
  • Rear Axle: metal shaft with ball differential
  • Primary: Spur/pinion
  • Bearings: High-speed ball-bearings (13)


Suspension

  • Front: Spring-supported, kingpin-style front suspension system with composite steering obstructs and graphite upper & reduced suspension hands
  • back: Conventional rear pod, adjustable via pivot-ball links, controlled by side tubes
  • Rear Shock: Central adjustable oil-filled surprise absorber


Geometry

  • Ride Height: Adjustable front + rear
  • Camber: Adjustable front
  • Front Caster: 3–12° adjustable caster
  • Track-width: Adjustable front + rear
  • Toe: Adjustable front
  • Downstop: adjustable front + rear
  • Anti-roll club: 1.2 mm front
  • Ackermann: adjustable with servo saver supply and steering block
  • Steering: Direct linkage between steering supply and steering blocks
  • Balance: Front/rear weight stability adjustable via battery place


Other

  • Wheels: maybe not included
  • Tires: perhaps not included
  • Instructions: complete colour instruction manual
  • Packaging: Carton package with vinyl bags with parts
  • Additionally included: Lexan Formula body & front wing, HUDY Diff Grease, Authentication Certificate, components list & exploded view, shock oil
  • Not included: Radio system (transmitter and receiver), steering servo, engine, pinion gear, battery power, rate controller, charger, tires, tires, inserts, high-strength fiber tape, double-sided tape, CA glue, bearing oil, tools
Remark :
Due to limited stock availability, please notice that some XRAY items may have to order from the factory and the ready time is around 4-6 weeks. Customer purchases the item is assumed to accept the waiting time which allows us to order directly from the manufacturer if the item is out of our warehouse.
